New product
Product Description
Usage Range
Hardened and surface hardened steel, hardening and tempering steel, tempered steel, cold and hard casting parts, forging parts, hard alloy steel, aluminum alloy, bearing steel, carburized steel sheet, etc.
Technical Specifications
|
Rockwell Scales
|
HRA, HRB, HRC, HRD, HRE, HRF,HRG,HRH,HRK
|
|
Initial Testing Force
|
10kgf (98N）
|
|
All Testing Force
|
60kgf (588N), 100kgf (980N), 150kgf (1471N)
|
|
Indication of Hardness Value
|
Dial
|
|
Overall Dimension
|
520×240×700mm(L×W×H)
|
|
Net Weight
|
80kg
|
|
Max Height of Speciment
|
170mm
|
|
Max depth of speciments
|
165mm
|
|
Carried Standard
|
GB/T230(1.2) Chinese Standard
|
|
Standard Accessories
|
Diamond Rockwell Indenter, Diameter 1.5875mm Hard Alloy Steel Ball Indenter, Large Testing Table , Medium Testing Table and Vshaped Testing Table, HRC and HRB Hardness Blocks.
|
