C71 Ultrasonic Cross-hole Automatic Foundation Pile Testing System
Application
1, Continuous rapid testing of building foundation piles by cross-hole sonic logging
2, Inspection of concrete defects by ultrasonic method, such as uncompacted, cellular, hole area and so on
3, Detecting strength of concrete by ultrasonic-rebound combine method
4, Detecting strength of concrete crevice by ultrasonic-rebound combine method
5, Detecting defects of one hole by one trigger two receive.
6, Testing mechanical properties of non-metallic material, such as rock, concrete etc.
Performance
1, High efficient testing: lifting speed more than 60m/s(20cm distance).
2, Display test data graphically: watch analyze result directly.
3, Fast and precise automatic judge sound parameters: real-time wave display to ensure test efficiency.
4, Humanized software design, apply to user and construction plant. Ensure user handle it easily.
5, Linking the rebound apparatus directly, detecting strength of concrete by ultrasonic-rebound combine method with linking rebound apparatus directly, and get strength of concrete in time.
6, Being sensitive to receiving signal: receive signal more than 10m in concrete without defects.
7, Can supply smooth power for radial energy transducer needless external power
8, Standard USB storage with big capacity
9, Interior lithium battery, work more than 6 hours
10, Portable, impact design and light apparatus
11, extending function for testing thickness of concrete by impacting echo method
12,Professional and powerful analysis software. Export the data to excel or word for advance analysis.
Technical Data
|
Item |
Specification |
Item |
Specification |
|
Main control unit |
high-performance embed computer |
Display |
640*480, LCD high brightness TFT |
|
Input |
Keyboard |
Storage |
1G(internal)+2G(U Disk) |
|
Interface |
USB |
Maximum hoisting speed |
60m/min(20cm distance) |
|
Receive Channel |
Two |
Maximum sampling length |
64k |
|
Trigger Mode |
Continuous trigger, external trigger |
Transmit Voltage(V) |
65, 125, 250, 500, 1000 selectable |
|
Receive sensitivity |
≤30μv |
Amplifier gain |
82dB |
|
Amplifier bandwidth |
5Hz～500kHz |
Sampling Interval |
0.05μs～6.4μs |
|
Phonatory time accuracy |
0.05μs |
amplitude resolution |
0.39% |
|
Power |
Interior lithium battery, more 6hours |
Connect concrete hammer |
YES |
|
(optional) external lithium battery, more than 6hours |
Dimension of Frame |
260 mm×185 mm×60 mm |
|
|
DC 12V |
Weight |
1.75 |
|
|
AC 100V-240V, 50/60Hz |
Work temperature |
—10 to +40 degree |
